The UK National Electricity Transmission System Dataset

A time series of the national grid demand (high-voltage electric power transmission network) in the UK since 2011.

An R data package with the UK National Grid historical demand for electricity between 2011 and 2018

Overview

The UKgrid dataset is an example of a multiple seasonality time series. This time series captures the demand for electricity and its components in the UK since 2011 using half-hour intervals. In addition, the package provides a function to extract, subset and aggregate the series into ts, xts, zoo, data.frame, data.table, or tbl.

The data was sourced from the National Grid UK website

Installation

Install the development version from Github:

devtools::install_github("RamiKrispin/TSstudio")

Usage

library(UKgrid)

# Load the full dataset (data.frame format)
data("UKgrid")

# Extract only the demand field (ND - Net Demand) using xts format
extract_grid(type = "xts",
             columns = "ND")

# Extract the demand between 2016 and 2017 using tbl format
extract_grid(type = "tbl",
             columns = "ND",
             start = 2016,
             end = 2017)

# Extract the first 10 days in 2018 and aggregate to hourly using zoo format
extract_grid(type = "zoo",
             columns = "ND",
             start = as.Date("2018-01-01"),
             end = as.Date("2018-01-10"),
             aggregate = "hourly")
